Tysim Piling Rig Machine For Building Foundation Kr60 Rotary Drill

Name: Tysim Piling Rig Machine For Building Foundation Kr60 Rotary Drill
Brand: Tysim
Price: 1 USD

Quality Tysim Piling Rig Machine For Building Foundation Kr60 Rotary Drill for sale

Brand Name : Tysim

Model Number : KR60

Certification : CE, ISO 9001:2000

Place of Origin : Jiangsu, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 30 per month

Delivery Time : 45 days

Packaging Details : nude or case packaged

Max. Drilling Depth : 20 M

Operating Height : 10600 mm

Specification : 20 t

Contact Now

Product Description

Tysim Piling Rig Machine For Building Foundation Kr60 Rotary Drill

Technical Specification

Type	KR60A
Torque	60 KN.m
Max. diameter	1200 mm
Max. drilling depth	20 m
Speed of rotation	8~30 rpm
Max. crowd pressure	60 kN
Max. crowd pull	90 kN
Main winch line pull	65 kN
Main winch line speed	48 m/min
Auxiliary winch line pull	20 kN
Auxiliary winch line speed	48 m/min
Stroke(crowd system)	2000 mm
Mast inclination(lateral)	±3°
Mast inclination(forward)	4°
Max. operating pressure	34.3 MPa
Pilot pressure	3.9 MPa
Travel speed	3 km/h
Traction force	98 kN
Operating height	10600 mm
Operating width	2700mm
Transport height	3250 mm
Transport width	2700 mm
Transport length	9500mm
Overall weight	20 t

Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
